微波雷達感測器開關系列 Microwave (Radar) Sensor Switch Series |
|
|
|
Model No. |
21-4114 |
|
|
Working Voltage |
AC110 - 220V 50/60Hz |
|
|
Controllable Loading |
≦ 40W ≦ 5 lamps |
|
|
Standby power consumption |
≦ 1W (Standby) |
|
|
Start Lux Setting |
<10 Lux |
|
|
Induction range |
The radius of the induction top is 1-2 meter and the wall is 4-6 meters |
|
|
Time delayed |
40±10secs |
|
|
Detection angle |
110°. |
|
|
Mounting height |
1.5m (ceiling installation); <3.5m (wall installation). |
|
|
Operating temperature |
-20℃ ~ 45℃ |
|
|
IP rating |
IP 20 |
|
|
Size (mm) |
Ø40 (suggest to install Ø26) |
|
|
Packing |
Quantity: 10pcs/Box, 50Box / Carton |
|
|
||
