美隆電子有限公司

PIR- 紅外線感測器開關系列

Infrared sensor switch series

Data Specification.

Model No.

21-4115X

21-4115B

Working Voltage

AC220V  50Hz

AC220V  50Hz

Controllable Loading

≦ 300W ≦ 3 lamps

≦ 100W ≦ 5 lamps

Standby power consumption

≦ 1W (Standby)

Start Lux Setting

< 10Lux

Induction range

The radius of the induction top is 1-2 meter and the wall is 4-6 meters

Time delayer

40±10s

Detection angle

110°

Mounting height

1.5m (Ceiling installation): <3.5m.(Wall installation)

Operating height

-20 ℃ ~ 45 ℃

IP Rating

IP20

Size (mm)

L:68xW:32xH:25

• 「本公司保留隨時修改或變更內容之權利，恕不另行通知。」
• 「The company reserves the right to modify or change the content at any time without prior notice."
