RESISTOR SERIES

-

Resistor
電阻

RESISTOR SERIES

-

CEMENT RESISTOR

TYPE	Power Range	Resistance Range (Ω)	Figure	TYPE	Power Range	Resistance Range (Ω)	Figure
CM-SQH	10W ~ 40W	0.5R ~ 100R		CM-SQV	5W ~ 50W	0.1R ~ 100R
CM-SQP	2W ~ 40W	0.5R ~ 200R		CM-MPH	4W	0.1R ~ 33R
CM-SQM	2W ~ 10W	0.1R ~ 500R		CM-AH	5W ~ 300W	0.1R ~ 3.3K
CM-SQT	5W ~ 25W	0.1R ~ 100R		CM-MPR	3W ~ 7W	0.01R ~ 1R
CM-SQZ	3W ~ 30W	0.1R ~ 100R		CM-PHD	10W ~ 3KW	1R ~ 1M

大功率電阻

MELF Resistor

MELF Resistor Series (晶圓電阻系列)

功率

型號

功率

型號

功率

型號

功率

型號

功率

型號

功率

型號

功率

型號

1/8W

W-MAS02

1/8W

W-MCF04

1/8WS

W-MMF02

1/4W

V-MMG07

1/4W

V-MMO07

1/8WS

W-MPM01

1/8W

W-FRM04

1/4W

V-MAS04

1/4WS

V-MCF04

1/8W

W-MMF04

1/2WS

U-MMG07

1/2WS

U-MMO07

1/8W

W-MPM04

1/4S

V-FRM04

1/2W

U-MAS07

1/4W

V-MCF07

1/4WS

V-MMF04

1WS

S-MMG07

1/2W

U-MMO07

1/4WS

V-MPM04

1/4W

V-FRM07

S-MAS09

1/2WS

U-MCF07

1/4W

V-MMF07

S-MMG09

1WS

S-MMO07

1/4W

V-MPM07

1/2WS

U-FRM07

Q-MAS11

1WS

S-MCF07

1/2WS

U-MMF07

Q-MMG11

S-MMO11

1/2WS

U-MPM07

1/2W

U-FRM09

N-MAS15

1WS

S-MCF09

1WS

S-MMF07

N-MMG15

2WS

Q-MMO11

1WS

S-MPM07

1WS

S-FRM09

2WS

Q-MCF11

S-MMF09

3WS

N-MMO15

1WS

S-MPM09

S-FRM11

3WS

N-MCF15

2WS

Q-MMF11

2WS

Q-MPM11

2WS

Q-FRM11

3WS

N-MMF15

3WS

N-MPM15

Q-FRM15

3WS

Fusible Resistor

Fusible Resistor
TO220 Power Resistor

TO220 Power Resistor

NTC Thermistor

NTC SMD Thermistor 傳感器熱敏電阻

Data Sheet NTC SMD Thermistor
SMD Type	Resistance	Tolerance	B-constand	Mix.Power	Constant	Temperature
SMD Type	25℃ Ω	Tolerance	(25-85℃) k	Rating 25℃ (k)	(mW/℃)	(℃)
SMD02 (0402)	1K ~ 470K	±1%; ±2%;±3%; ±5%.	3150 ~ 4750	250	2.5	-165
SMD03 (0603)	1K ~ 560K	±1%; ±2%;±3%; ±5%.	3550 ~ 4100	350	3.5	-165
SMD05 (0805)	1K ~ 330K	±1%; ±2%;±3%; ±5%.	3150 ~ 4100	400	4	-165
NTC
