LED 廣告燈箱 40W

LED Message Box

SINLOON^®	LED薄型平面告廣燈箱(單/雙面板)系列				明亮奪目塑造獨特風格
	Message Sign (Single/Double Panel) - Series				Model No.	A6080 (40W)
				'	'	'
LED Message Light Box A6080 (40W)
□ Feature:
Frame measurement:		Standard size.				'	'
Frame material:		Aluminum metal
Voltage Type:		Constant current (External adaptor)
Temperature Color:		White				'	'
Input voltage:		AC110~240V 50/60Hz
Light source:		LED SMD5630 type
Shine:		To product light not flashing				'	'
Framework:		Arc angle shaped
Panel:		Ultra-thin guiding light, Energy conservation
□ Characteristic Parameters:					'
型號 Model No.:			MLL-A6080D (Double Panel)		MLL-A6080S (Single Panel)
尺寸 Dimension (LWT):			64489116.5mm		64489111.2mm
發光尺寸 The Emitting Size:			854*831mm		584*831mm
輸入電壓(外置電源) Input Voltage			AC110V~240V 50/60Hz		AC110V~240V 50/60Hz
輪出電壓 Output Voltage: (AC/DC Adaptor)			28.8V DC		28.8V DC
電流 Current:			1.2A		1.2A
類型 LED Type:			SAMSUNG LED - SMD5630		SAMSUNG LED - SMD5630
數量 LED Quantity:			90pcs		90pcs
功率 System Power (W)			40W ±5%		40W ±5%
亮度 Brightness (on the surface panel)			3500 Lux		7000 Lux
色溫 Color Temperature (K)			Color: White 6000K ±8%		Color: White 6000K ±8%
顯色指數 Color Rendering Index:			80±2		80±2
發光角度 Illumination Angle:			120^o		120^o
壽命 Lifespan:			40000hrs (25℃)		40000hrs (25℃)
環境溫度 Ambient Temperature (℃):			-20℃ ~ 50℃		-20℃ ~ 50℃
重量 Weight (Kg):			<8.0/kg		<6.5/kg
認證 Certificate:			BSMI/CE/RoHS/FCC		BSMI/CE/RoHS/FCC
* If you have any question which is not is in the specification, please contact us.
*在本規格書裡如果您未能找到或參數指標未能達到你的應用要求即未在本規格書裡表現出來請與我們聯絡.
