T5 T8 LED 防水燈管支架
| SINLOON® | LED U型明裝燈盤系列 | T8 LED U-Type Batten | |||||||
| LED Batten Single/Double-barreled | |||||||||
  |
Data: | U型燈盤 |
|||||||
| Body Fixtures: | Figure: | ||||||||
| The chassis uses high quality cold rolled steel with standard acid packing, |  |
||||||||
| The product has been static electricity spray painted with environmental | |||||||||
| power. It can be resistant to rust. | |||||||||
| The service life of LED tube can be 50000hrs. The way of power supply | |||||||||
| AC input double and version. | - | ||||||||
| The voltage is AC110V-277V | |||||||||
| Describe of the lighting fixture: | |||||||||
| 型號 | 類型 | 本體燈盤尺寸 /單位 (mm) | 面罩 | ||||||
| 型別 | 型式 | L | W | H | |||||
| U-T8-LED061009x1 | T8 | 2FT9W | 600 | 100 | 90 | 單燈管 | 膠片板 | 棱境 | |
| U-T8-LED121009x1 | T8 | 4FT18W | 1200 | 100 | 90 | 單燈管 | 膠片板 | 棱境 | |
| U-T8-LED151009x1 | T8 | 5FT22W | 1500 | 100 | 90 | 單燈管 | 膠片板 | 棱境 | |
| U-T8-LED061706x2 | T8 | 2FT18W | 650 | 175 | 65 | 雙燈管 | 膠片板 | 棱境 | |
| U-T8-LED121706x2 | T8 | 4FT36W | 1250 | 175 | 65 | 雙燈管 | 膠片板 | 棱境 | |
| U-T8-LED151706x2 | T8 | 5FT44W | 1550 | 175 | 65 | 雙燈管 | 膠片板 | 棱境 | |
| Metal material thick: ~1.2mm | |||||||||
| 註: | 產品尺寸最終依實物為準. | ||||||||
 |
 |
 |
|||||||
| 應用: (T5/T8燈管系列照明燈具) | - | ||||||||
| 場地用途:工廠商廈走廊通道,學校,超市,倉庫,寫字樓,餐廰等室內照明等場合,適用範圍廣泛. | |||||||||
| Applying: Industrial factory buildings, underground packing lots, schools, shopping malls. | |||||||||
| 產品描述: | |||||||||
| 燈具殼體採用高強度優質鋼板,表面静電噴塑處理,粉體黏附力強,色澤均勻,防銹和不易脫漆。 | |||||||||
| 本體經鉚接而成,側面有加強筋設計結構,高強度,使燈具不易扭曲變形。 | |||||||||
| 燈座及接線端子均採用阻燃PC材料,符合國家3C標準。 | - | ||||||||
| 接駁電線耐溫90℃,耐壓300-500V。 | |||||||||
| 安裝方式可採用吸頂, 吊杆,吊鏈式,靈活應用。 | |||||||||
 |
|||||||||
